MULTIRIB (POLY-V) BELTS

Poly-V Belts are ideally suited for high speed, and or high drive ratio applications that conventional V-Belts just can not handle.Poly-V Belts offersmooth vibration-free performance in a single compact drive belt. Well suited for applications such as appliances, outdoor power equipments, roller conveyors, machine tools, medical equipments and exercise equipments. Fiber Reinforced Ribs for excellent wear resistance, High modulus, low stretch tensile member for added strength and dependability, smooth running for minimal vibration at high speeds, up ti 80% higher horsepower capacity than RMA standarts, oil and heat resistance and statically conductive. We have sections are: (PH, PJ, PK, PM, PL available) PK SECTION MOSTLY USED IN AUTOMOTIVE APPLICATIONS



Product Range

Section Top Width Height Length Range
AVX10 10 mm 8 mm 500 - 6000 mm
AVX13 13 mm 9 mm 500 - 6000 mm
AVX15 15 mm 9 mm 500 - 6000 mm
AVX17 16,5 mm 11 mm 500 - 6000 mm
AVX22 22 mm 13 mm 500 - 6000 mm
15 15/32" 5/16"/td> 20 - 195"
17 17/32" 11/32"/td> 25 - 195"
22 22/32" 7/16"/td> 30 - 195"
28 28/32" 9/16"/td> 35 - 195"
